Supermicro SuperServer 4029GP-TRT3 Barebone System - 4U Rack-mountable - Socket P LGA-3647 - 2 x Processor Support - Intel C622 Chip - 6 TB DDR4 SDRAM DDR4-2933/PC4-23466 Maximum RAM Support - 24 Total Memory Slots - Serial ATA/600 RAID Supported Controller - ASPEED AST2500 Graphic(s) - 34 2.5" Bay(s) - 10 SATA Interface(s) - Processor Support (Xeon Gold, Xeon Platinum, Xeon Silver, Xeon Bronze) - 10 Gigabit Ethernet - Intel Optane Memory Ready - 4 USB 3.0 Port(s) - 4 x 2000 W - 1 Year
OVERVIEW:
- SuperServer 4029GP-TRT3 (Black)
- 1 x Super X11DPG-OT-CPU Motherboard
- 1 x Super X11DPG-O-PCIE Motherboard
- 1 x CSE-418GTS-R4000BP2 Chassis
- 1 x 24-port 2U SAS3 12Gbps hybrid backplane, support up to 20x 2.5-inch SAS3/SATA3 HDD/SSD and 4x SAS3/SATA3/NVMe Storage Devices
- 2 x HDD power extension for X8OBN, special 8 pin to 4 HDD. 45cm. 18AWG
- 8 x GPU,2x4F/CPU to 2x4F/CPU,P4.2, 30CM,16AWG, 10A/pin, -40~105C
- 2 x MINI SAS HD-MINI SAS,6G,INT,80CM,SB,28AWG
- 2 x OcuLink V. 1.0 source to MiniSAS HD,INT,PCIe, 70CM,34AWG,RoH
- 1 x Black plastic palm cover for X10DRG-O-PCIE
- 4 x RSC-X9DRG-O
- 2 x 2U Active CPU Heat Sink Supporting Narrow Bolster Plate Mounting Mechanism for X11 Purley Platform
- 4 x 1U 2000W Redundant Titanium Power Supply W/PMbus 73.5x40x265mm,RoHS/REACH
- 1 x CBL,FRONT CNTL,16 TO 16 PIN,RA,RND TUBE,75CM,28AWG
- 4 x PWCD,US,NEMA5-15P TO IEC60320 C13,6FT,14AWG,15A,125V,RoHS/REACH
- 8 x 92x92x38 mm, 11.5K RPM, SC418G Middle Fan w/ Housing,RoHS/REACH,PBF
- 24 x Black gen 3rd hot-swap 2.5inch HDD tray
- 1 x 21 slot rear window for SC418X
- 1 x IO shield for X9DRG-O in SC418G
- 1 x Front control board adapter (TB826) for SC216,826,936,846
- 1 set Rail set, quick/quick, default for 4U 17.2"; W
- 1 x Threaded rail adapter default for round hole rack
- 3 x Black 2.5\" HDD dummy cover for SC213,216 (Cover 8 HDD)
- 1 x Inner rail, quick-release type
- 1 x Outer rail, quick-release type
- 1 x 92x92x38 mm, 11.5K RPM, 4-pin PWM Bare Fan
Additional Info
Additional Info
| SKU | 03287SYS4029GPTRT3-BF |
|---|---|
| Weight | 65.4800 |
| Is Featured | N/A |
| Manufacturer | Supermicro Computer, Inc |
| Manufacturer Part Number | SYS-4029GP-TRT3 |
| Width | 17.2" |
| Length | 1 |
| Height | 7" |
| Product ID | 03287SYS4029GPTRT3 |
| UNSPSC | N/A |
| Other Part Number | N/A |
| Special Price | N/A |
