Supermicro SuperServer 4028GR-TRT Barebone System - 4U Rack-mountable - Socket R LGA-2011 - 2 x Processor Support - Intel C612 Chip - 1.50 TB DDR4 SDRAM DDR4-2133/PC4-17000 Maximum RAM Support - 24 Total Memory Slots - Serial ATA/600 RAID Supported Controller - ASPEED AST2400 Graphic(s) - 24 2.5" Bay(s) - 4 SATA Interface(s) - Processor Support (Xeon) - 10 Gigabit Ethernet, Gigabit Ethernet - 4 USB 3.0 Port(s) - 4 x 1600 W - 3 Year
OVERVIEW:
- SuperServer 4028GR-TRT (Black)
- 1 x Super X10DRG-OT+-CPU Motherboard
- 1 x CSE-418GTS-R3200B Chassis
- 1 x Mylar PCIe air shroud for SC418G (X9DRG-O-PCIE),PBF
- 1 x Mylar CPU air shroud for SC418G (X9DRG-OF-CPU),PBF
- 1 x 24x 2.5"HDD backplane, support SAS-3 12Gb/s,mini-SAS HD connector,new 29-pin SAS-3 receptacles,support power control stagger spin,pre-charge resistor,fuse protect and SGPIO encl mgmt,RoHS/REACH,PBF
- 2 x HDD power extension for X8OBN, special 8 pin to 4 HDD. 47cm. 18AWG
- 8 x 8 pin to two 6+2 pin 12V GPU power cable, 30 cm 16/20 AWG,HF,RoHS/REACH,PBF
- 2 x cross-over mini SAS HD to 4 SATA w/SB, S. 75cm. 30AWG,HF,RoHS/REACH,PBF
- 1 x CAUTION LABEL FOR REDUNDANT PWR SYSTEMS
- 1 x SYS-4028GR-TR(T) Quick Reference Guide,HF,RoHS/REACH
- 4 x RSC-X9DRG-O
- 2 x 2U Passive CPU Heat Sink for X9, X10 Generation Systems Equipped w/ a Narrow ILM MB
- 4 x 1U 1600W Redundant Platinum Power Supply 73.5mm width,RoHS/REACH,PBF
- 8 x 92x92x38 mm, 11.5K RPM, SC418G Middle Fan w/ Housing,RoHS/REACH,PBF
Additional Info
Additional Info
| SKU | 03287SYS4028GRTRT-BF |
|---|---|
| Weight | 79.8100 |
| Is Featured | N/A |
| Manufacturer | Supermicro Computer, Inc |
| Manufacturer Part Number | SYS-4028GR-TRT |
| Width | 17.2" |
| Length | 1 |
| Height | 7" |
| Product ID | 03287SYS4028GRTRT |
| UNSPSC | N/A |
| Other Part Number | N/A |
| Special Price | N/A |
