Supermicro SuperServer 2029TP-HC0R Barebone System - 2U Rack-mountable - Socket P LGA-3647 - 2 x Processor Support - Intel C621 Chip - 4 TB DDR4 SDRAM DDR4-2933/PC4-23466 Maximum RAM Support - 16 Total Memory Slots - 12Gb/s SAS RAID Supported, Serial ATA

The Supermicro TwinPro architecture is based on the Supermicro proven Twin technology to provide exceptional throughput, storage, networking, I/O, memory and processing capabilities in a 1U/2U form factor. Customers can further optimize Supermicro solutions to resolve the most challenging IT requirements and benefit from exceptional Total Cost of Ownership (TCO).

TwinPro solutions are designed for simplified deployment and maintenance, and assembled with the highest quality to ensure continuous operation even at maximum capacity. Customers in high-end enterprise, data center, HPC and Cloud Computing environments receive the greatest competitive advantage from data center resources with the Supermicro TwinPro.

Performance: The latest generation of Intel® Xeon® processors significantly heighten performance of Supermicro TwinPro solutions. With up to 28 cores per socket, 6 channels of DDR4 and up to 2TB of DDR4-2666 in 16 DIMM slots, memory speeds will reach a maximum of 2666MHz. Supermicro X11 TwinPro systems are optimized to deliver incredible performance to high performance environments and will handle complex workloads with ease.
Flexibility: High flexibility and various networking options are key features of the TwinPro. Each node includes a Supermicro I/O Module (SIOM) for networking options such as 1G, 10G, 25G, 40G or 100G and 2 low-profile PCI-E 3.0 x16 expansion slots, giving our customers the flexibility to include add-on cards when they are required.
Efficiency: The Supermicro Twin Architecture product line delivers the industry's densest, cost -efficient servers. The TwinPro doubles the performance of a traditional 1U/2U system and houses four nodes to reduce data center footprint and includes redundant Titanium Level Digital (96%) Power Supplies for maximum power efficiency.

Availability: Call or email

$5,901.26

Qty:

Description

Details

Supermicro SuperServer 2029TP-HC0R Barebone System - 2U Rack-mountable - Socket P LGA-3647 - 2 x Processor Support - Intel C621 Chip - 4 TB DDR4 SDRAM DDR4-2933/PC4-23466 Maximum RAM Support - 16 Total Memory Slots - 12Gb/s SAS RAID Supported, Serial ATA Controller - ASPEED AST2500 Graphic(s) - 6 2.5" Bay(s) - Processor Support (Xeon Platinum, Xeon Gold, Xeon Silver, Xeon Bronze) - Ethernet - Intel Optane Memory Ready - 2 USB 3.0 Port(s) - 2 x 2200 W - 3 Year

OVERVIEW:

Chipset Manufacturer : Intel

Number of Nodes : 4

Limited Warranty : 3 Year

Input Voltage : 230 V AC

Input Voltage : 120 V AC

Ethernet Technology : Ethernet

Package Contents :

SuperServer 2029TP-HC0R (Black)
4 x Super X11DPT-PS Motherboards
1 x 2U Chassis
4 x LSI 3008, SAS 12Gbs (X6 port inside)
1 x 2U 24-Port 4-Node Backplane Supports 6x2.5
2 x PWCD,US,IEC60320 C14 TO C13,3FT,14AWG
4 x Twinpro X11 air shroud
4 x RSC-P-6 (1U LHS TwinPro RSC with 1 PCI-Ex16),RoHS
4 x 1U RHS TwinPro Riser card with one PCI-E x16 slot
4 x 1U Passive CPU Heat Sink for X11 Purley Platform Equipped with a Narrow Retention Mechanism
4 x 1U Passive CPU Heat Sink with a 26-mm Wide Middle Air Channel for X11 Purley Platform Equipped with a Narrow Retention Mechanism
2 x 1U 2200W Redundant, Titanium, 76(W) X 40(H) X 336(L) mm

Maximum Memory Supported : 4 TB

Number of Total Expansion Bays : 6

Controller Type : Serial ATA

Controller Type : 12Gb/s SAS

Chipset Model : C621

Number of Processors Supported : 2

Product Color : Black

Memory Technology : DDR4 SDRAM

RAID Supported : Yes

Number of Power Supplies Installed : 2

Form Factor : Rack-mountable

Environmentally Friendly : Yes

Memory Standard : DDR4-2933/PC4-23466

Processor Socket : Socket P LGA-3647

Maximum Power Supply Wattage : 2200 W

Rack Height : 2U

Environmental Certification : RoHS

Number of Total Memory Slots : 16

Number of Internal 2.5" Bays : 6

Total Number of USB Ports : 2

Processor Supported : Xeon Bronze

Processor Supported : Xeon Silver

Processor Supported : Xeon Gold

Processor Supported : Xeon Platinum

Height : 3.5"

Number of USB 3.0 Ports : 2

Width : 17.3"

Intel Optane Memory Ready : Yes

Number of Total Expansion Slots : 2

Depth : 28.5"

Graphics Controller Manufacturer : ASPEED

Weight (Approximate) : 72.09 lb

Graphics Controller Model : AST2500

64-bit Processing : Yes

Number of PCI Express x16 Slots : 2

Number of SAS Interfaces : 6

Additional Info

SKU	03287SYS2029TPHC0R-BF
Weight	72.0900
Is Featured	N/A
Manufacturer	Supermicro Computer, Inc
Manufacturer Part Number	SYS-2029TP-HC0R
Width	17.3"
Length	1
Height	3.5"
Product ID	03287SYS2029TPHC0R
UNSPSC	N/A
Other Part Number	N/A
Special Price	N/A
