Supermicro SuperServer 2029BT-HNTR Barebone System - 2U Rack-mountable - Socket P LGA-3647 - 2 x Processor Support - Intel C621 Chip - 6 TB DDR4 SDRAM DDR4-2933/PC4-23466 Maximum RAM Support - 24 Total Memory Slots - Serial ATA Controller - ASPEED AST2500

The Supermicro BigTwin™ is the first and only 2U multi-node system supporting the highest performance processor, memory, storage, I/O and an incredible 30% better thermal capacity. The 5th generation of Supermicro's Twin architecture is fully optimized for today's diverse workloads and architected for further technology breakthroughs.

Performance: Supporting the 2nd generation Intel® Xeon® Scalable processors up to 205W, the BigTwin achieves incredible performance in a 2U multi-node platform. Each node of the BigTwin supports up to 6TB DDR4-2933MHz in 24 DIMM slots for dramatically faster and increased memory capacity compared to previous generations of Twin systems, as well as support for Intel® Optane™ DC Persistent Memory. With up to 12 hot-swappable 2.5" drive bays per node, storage performance is accelerated with options for All-Flash NVMe, SAS or SATA drives.
Density: BigTwin systems boast incredibly high density with up to 4 hot swappable nodes in a 2U form factor, and double the I/O capacity of competitive 2U solutions. Support for Supermicro I/O Module (SIOM) enables flexible networking options of 1G, 10G, 25G, or 100G Ethernet or 100G InfiniBand/Omni-Path and frees up 2 low-profile PCI-E 3.0 x16 expansion slots per node.
Efficiency: Supermicro's Twin architecture is designed with power and cost efficiency in mind. The BigTwin reduces power consumption with shared cooling and power design, leveraging redundant 2200W high efficiency (96%) power supplies. Maximum compute in a 2U system enables data center footprints to be reduced by 50% compared to standard 2U servers with equivalent performance.

Availability: Call or email

$7,000.16

Qty:

Description

Details

Supermicro SuperServer 2029BT-HNTR Barebone System - 2U Rack-mountable - Socket P LGA-3647 - 2 x Processor Support - Intel C621 Chip - 6 TB DDR4 SDRAM DDR4-2933/PC4-23466 Maximum RAM Support - 24 Total Memory Slots - Serial ATA Controller - ASPEED AST2500 Graphic(s) - 6 2.5" Bay(s) - Processor Support (Xeon Platinum, Xeon Gold, Xeon Silver, Xeon Bronze) - Gigabit Ethernet - Intel Optane Memory Ready - 2 USB 3.0 Port(s) - 2 x 2200 W - 3 Year

OVERVIEW:

Chipset Manufacturer : Intel

Number of Nodes : 4

Limited Warranty : 3 Year

Input Voltage : 230 V AC

Ethernet Technology : Gigabit Ethernet

Package Contents :

SuperServer 2029BT-HNTR (Black)
4 x Super X11DPT-B Motherboard
1 x 2U Chassis
4 x Hybrid BPN to support 4 SATA and/or NVMe in addition to 2 SATA ports,HF,RoHS
1 x 2U 4-Node 24-Port Backplane Supports 2x2.5\" SATA3/SAS3 SSD/HDD and 4x2.5\"" SATA3/SAS3/NVMe Stoage Media per Node
2 x PWCD,US,IEC60320 C14 TO C13,3FT,14AWG
8 x Black Gen3 hot-swap 2.5 inch HDD tray with lock improved EMI
16 x Black Gen3 hot-swap 2.5 inch HDD tray with lock, orange tab
1 x 217B BigTwin type I (Impact) BPN retention bkt w/ foam assy
4 x Bigtwin air box for X11DPT-B(4pcs/set)
4 x Bigtwin 2U4N plastic air shroud (2pcs) for Cascade lake MB
1 x 2029BT-H(N/T/NC0)R Quick Reference Guide
4 x RSC-P-6 (1U LHS TwinPro RSC with 1 PCI-Ex16),RoHS
4 x 1U RHS TwinPro Riser card with one PCI-E x16 slot
4 x 1U Passive CPU Heat Sink for X11 Purley Platform Equipped with a Narrow Retention Mechanism
4 x 1U Passive CPU Heat Sink with a 26-mm Wide Middle Air Channel for X11 Purley Platform Equipped with a Narrow Retention Mechanism
2 x 1U 2200W Redundant Power Supply Titanium, 45(W) X 40(H) X 48

Maximum Memory Supported : 6 TB

Number of Total Expansion Bays : 6

Controller Type : Serial ATA

Chipset Model : C621

Number of Processors Supported : 2

Product Color : Black

Memory Technology : DDR4 SDRAM

Number of Power Supplies Installed : 2

Form Factor : Rack-mountable

Environmentally Friendly : Yes

Memory Standard : DDR4-2933/PC4-23466

Processor Socket : Socket P LGA-3647

Maximum Power Supply Wattage : 2200 W

Rack Height : 2U

Environmental Certification : RoHS

Number of Total Memory Slots : 24

Number of Internal 2.5"" Bays : 6

Total Number of USB Ports : 2

Processor Supported : Xeon Bronze

Processor Supported : Xeon Silver

Processor Supported : Xeon Gold

Processor Supported : Xeon Platinum

Height : 3.5""

Number of USB 3.0 Ports : 2

Width : 17.6""

Intel Optane Memory Ready : Yes

Number of Total Expansion Slots : 3

Depth : 28.8""

Graphics Controller Manufacturer : ASPEED

Weight (Approximate) : 54.50 lb

Graphics Controller Model : AST2500

64-bit Processing : Yes

Number of PCI Express x16 Slots : 2

Additional Info

SKU	03287SYS2029BTHNTR-BF
Weight	54.5000
Is Featured	N/A
Manufacturer	Supermicro Computer, Inc
Manufacturer Part Number	SYS-2029BT-HNTR
Width	17.6"
Length	1
Height	3.5"
Product ID	03287SYS2029BTHNTR
UNSPSC	N/A
Other Part Number	N/A
Special Price	N/A

Supermicro SuperServer 2029BT-HNTR Barebone System - 2U Rack-mountable - Socket P LGA-3647 - 2 x Processor Support - Intel C621 Chip - 6 TB DDR4 SDRAM DDR4-2933/PC4-23466 Maximum RAM Support - 24 Total Memory Slots - Serial ATA Controller - ASPEED AST2500
