Cisco HyperFlex Server Barebone System - 2U Rack-mountable - 2 x Processor Support - Intel C621 Chip - 3 TB DDR4 SDRAM DDR4-2933/PC4-23466 Maximum RAM Support - 24 Total Memory Slots - 12Gb/s SAS RAID Supported Controller - G200e 16 MB Graphic(s) - Networ

Cisco HyperFlex Edge Systems are optimized for remote sites, branch offices, and edge environments. As a smaller form factor of Cisco HyperFlex, Cisco HyperFlex Edge keeps the full power of a next generation hyperconverged platform even without connecting to Cisco UCS Fabric Interconnects. Cisco HyperFlex Edge Systems support a variable configuration of 2, 3, or 4 HX converged nodes and supports the scale up of CPU, memory, and storage capacity (hot-add additional capacity drives).

HyperFlex Edge operates using existing top of rack 1GE or 10/25GE switching with options for both single and dual switch configurations. HyperFlex Edge is typically deployed in environments with a minimal infrastructure footprint, hence the use of UCS compute-only nodes is not supported.

The HyperFlex HXAF-E-240/HX-E-240 M5 Edge server extends the capabilities of Cisco's HyperFlex portfolio in a 2U form factor with the addition of the 2nd Gen Intel® Xeon® Scalable Processors, 12 DIMM slots per CPU for 2933-MHz DDR4 DIMMs with DIMM capacity points up to 128 GB. The maximum memory capacity for 2 CPUs is listed here:

  • 3 TB (24 x 128 GB DDR4 DIMMs)

Availability: Call or email

$2,306.15
$2,306.15
Cisco Systems, Inc

Description

Details

Cisco HyperFlex Server Barebone System - 2U Rack-mountable - 2 x Processor Support - Intel C621 Chip - 3 TB DDR4 SDRAM DDR4-2933/PC4-23466 Maximum RAM Support - 24 Total Memory Slots - 12Gb/s SAS RAID Supported Controller - G200e 16 MB Graphic(s) - Network (RJ-45) - 1 M.2 Interface(s) - Processor Support (Xeon Gold, Xeon Silver, Xeon Bronze, Xeon Platinum) - 10 Gigabit Ethernet, Gigabit Ethernet - Windows Server 2019 Datacenter, Windows Server 2019 Standard Supported Operating System - Inte

OVERVIEW:

  • Operating System Supported : Windows Server 2019 Standard
  • Operating System Supported : Windows Server 2019 Datacenter
  • Chipset Manufacturer : Intel
  • Input Voltage : 230 V AC
  • Input Voltage : 120 V AC
  • Ethernet Technology : Gigabit Ethernet
  • Ethernet Technology : 10 Gigabit Ethernet
  • Maximum Memory Supported : 3 TB
  • Number of Total Expansion Bays : 24
  • Controller Type : 12Gb/s SAS
  • Chipset Model : C621
  • Number of Processors Supported : 2
  • Memory Technology : DDR4 SDRAM
  • RAID Supported : Yes
  • Form Factor : Rack-mountable
  • Memory Standard : DDR4-2933/PC4-23466
  • Rack Height : 2U
  • Total Number of USB Ports : 2
  • Processor Supported : Xeon Platinum
  • Processor Supported : Xeon Bronze
  • Processor Supported : Xeon Silver
  • Processor Supported : Xeon Gold
  • Height : 3.4"
  • Total Number of Memory Slots : 24
  • Number of USB 3.0 Ports : 2
  • Width : 19"
  • Total Number of Expansion Slots : 6
  • Depth : 30.4"
  • Intel Optane Memory Ready : Yes
  • Weight (Approximate) : 57.54 lb
  • Graphics Controller Model : G200e
  • Graphics Memory Capacity : 16 MB
  • Number of M.2 Interfaces : 1
  • 64-bit Processing : Yes
  • Network (RJ-45) : Yes
  • Number of Network (RJ-45) Ports : 3
  • Number of VGA Ports : 1
  • Additional Info

    Additional Info

    SKU 01468HXAFE240M5SX-BF
    Weight 57.5400
    Is Featured N/A
    Manufacturer Cisco Systems, Inc
    Manufacturer Part Number HXAF-E-240-M5SX
    Width 19"
    Length 1
    Height 3.4"
    Product ID 01468HXAFE240M5SX
    UNSPSC N/A
    Other Part Number N/A
    Special Price N/A
